Residential Energy Storage System
Solve the whole house
electricity consumption
EU certification
LFP Battery Cell
(EV-Level)
Peak power
2 times the load
Millisecond switching
technology
Intelligent Management
System
DC soft switching
technology
![E)Z8]R(9PIQM%9Z37$WW({4](/upload/label/1642749114690767.jpg "E)Z8]R(9PIQM%9Z37$WW({4")
90%
Discharge(DoD)
UN38.3
Certification
APP
Power Monitoring
4,000 METERS
Maximum Elevation
-20℃~60℃
Discharge
10 YEARS
Service life
IT CAN REALIZE THE RESIDENTIAL ELECTRICITY CONSUMPTIONTAKE 5kW FOR EXAMPLE
Charging,discharging,power management clear at a glance
20ms off/on-grid automatic switching
Solve the problem of intermittent power supply
the problem of power sales to the grid
the problem of spontaneous self-use,and the source of energy
Patented Products with Core Technology Muse Design Award Gold Pride(same as iphone12,Lynk & Co)
Authoritative certification to meet mainstream market
| Model | LC-E2-410 | LC-E2-520 | LC-E2-1025S (Single Phase) |
|---|---|---|---|
| Performance Specifications | |||
| Phase | Single Phase | ||
| Rated Output Power | 4000W | 5000W | 10000VA |
| Rated Output Current | 17.4A | 21.7A | 43.5A |
| Single Battery Capacity | 5.12kWh | ||
| No. of Expandable Batteries | 1~8 | 2~8 | 3~8 |
| Usable Capacity Range | 5.12~40.96kWh | 10.24~40.96kWh | 15.36~40.96kWh |
| Battery Type | LiFePO4 | ||
| Rated Output Voltage | （220V~240V）±5% | 230V | |
| Grid Voltage Range | 170~280V（UPS） 90~280V（APL) 183~253V(VDE) | 176~270V | |
| Rated Grid Frequency | 50HZ/60HZ Auto detect | ||
| PV Max Input Power | 4000W | 13000W | |
| MPPT Voltage Range | 64~130V | 125~500V | |
| System Charge&Discharge Efficiency | 93% | 98.2% | |
| Grounding Mode | TN | ||
| Swicthing Time | 10ms（UPS、VDE） 20ms（APL） | 20ms | |
| Design Lifespan | 10 Years | ||
| Warranty* | 5 years Product Warranty 10 years Performance Warranty | ||
| Compatible Parameter | |||
| Certifications | CE/TUV | ||
| Safety Regulations | IEC 62109-1&-2, IEC 62477, MSDS, EN 61000,UN38.3 | ||
| Grid Regulations | / | ||
| Mechanical Specifications* | |||
| Inverter Dimensions/Weight | 600/420/600mm/38.5kg | 600/420/600mm/65.5kg | |
| Battery Dimensions/Weight | 600/420/200mm/54kg | ||
| Base Dimensions/Weight | 600/420/130mm/17.5kg | ||
| Mounting Options | Stacking | ||
| Environmental Specifications | |||
| Operating Temperature* | -15℃~55℃ | ||
| Recommend Temperature | 25℃ | ||
| Altitude | 2000M | ||
| Humidity | 5%~95% Without Condensation | ||
| Ingress Rating | IP20 | IP21 | |
*Please observe our applicable warranty conditions.
*Under specific test conditions:100% depth of discharge(DoD),0.2C rate charge & discharge at 25℃.
*The dimension of the product shall be subject to the real object,with a tolerance of ±3%.
*When the temperature is below 0℃ or above 40℃,the performance will be limited.
